Cast Iron / Stainless Steel Self Priming Pump Manufacturers

Cast Iron / Stainless Steel Self Priming Pump Manufacturers

Stainless Steel Self Priming Pump

Self Priming Pump Manufacturers

Place of Origin:

China

Brand Name:

Huatao

Certification:

ISO 9001

Model Number:

HuaTao-Self Priming Pump

Contact Us

Request A Quote
Product Details
Name:
Self Priming Pump Manufacturers
Suction Height:
0~6m
Head:
5~ 125m
Material:
Cast Iron;304;316
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
USD 1500-5000 per set
Packaging Details
Wooden Box
Delivery Time
20-35 days
Payment Terms
L/C, T/T, Western Union
Supply Ability
2000 sets per month
Product Description

Material Cast IronSimple Structurep Self Priming Pump Synthetic Fiber Preservative



Self priming pump

The temperature-resistant and corrosion-resistant self-priming chemical centrifugal pump is a single-stage, single-suction chemical centrifugal pump with simple structure, light weight, durability, safety and reliability, bottomless valve, less failure, and can be used to transport solids (particles less than 3mm ) or corrosive liquids with suspended particles. Widely used in chemical industry, agriculture, metallurgy, synthetic fiber, food, medicine, brewing and other departments.
The pump is suitable for transporting corrosion-resistant media with a temperature range of 0°C to 150°C and solid particles smaller than 3mm.



Fearture of self priming pump

Product Name Slef priming pump
Material Cast Iron,Stainless Steel
Head 5~125
Power 0.55-90kw
Flow 0.3 ~ 400m³/h
Inlet diameter 25mm~400mm



The usage of self priming pump

The pump can transport concentrated syrup, syrup, distiller's grains, ash, and other conveying media containing particles or fibers of more than 3mm by replacing 3-4 parts.



Common Precautions for Slef Priming Pump  Applications:

1. Before starting, make sure the pump body and pipeline are full of material. Turn on the water inlet pump and close the inlet and outlet valves (start the pump under low load conditions).
2. After starting, slowly open the inlet and outlet valves, pay attention to the working pressure of the inlet and outlet pressure gauges, and ensure that the working pressure is stable at the pressure required by the process standard.
3. Pay attention to the vibration, noise, leakage and temperature rise of the pump body during operation. If there is any abnormal situation, it should be handled properly.
4. When the petrochemical pump is not running, it is necessary
