Cast Iron Vertical Turbine Water Pump Large Flow Rate For Water Liquld

Cast Iron Vertical Turbine Water Pump Large Flow Rate For Water Liquld

Cast Iron Vertical Turbine Water Pump

Vertical Turbine Water Pump Large Flow

Place of Origin:

China

Brand Name:

Huatao

Certification:

ISO 9001

Model Number:

HT-Axial-flow pump

Contact Us

Request A Quote
Product Details
Name:
Clean Water Axial Flow Pump
Flow:
700~13000 M³/h
Head:
2~ 25m
Power:
11KW-500KW
Voltage:
380V、660V、6kV、10kV
Usage:
Water
Material:
Cast Iron
Rotor Diameter:
300~1480mm
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
USD 20000-150000 per set
Packaging Details
Wooden Box
Delivery Time
35~50 days
Payment Terms
L/C, T/T, Western Union
Supply Ability
20 sets per month
Product Description

Material Cast Iron Large Flow Clean Water Axial-Flow Pump High Efficiency Turbine



Clean Water Axial-Flow Pump description



Axial-flow pump is a kind of pump that transmits liquid along the axis direction by the force generated by the blade of rotating impeller. There are several types of vertical, horizontal, oblique and tubular pumps. Adopting dedicated thrust bearings, with reasonable structural design, sufficient lubrication, good heat dissipation, long bearing service life, remote control and automatic control, time-saving and labor-saving installation and maintenance, and cost saving. Mainly suitable for low head and high flow situations, such as irrigation, drainage, dock drainage, water level regulation of canal locks, or as a large circulating water pump in power plants. The Axial-flow pump with high lift (double stage if necessary) can be used for water jet propulsion of shallow water ships



Clean Water Axial-flow pump Specification





Product name Axial-flow Pump
Material Cast Iron
Head 2~25m
Power 15~1400KW
Flow 700~13000m³/h
Usage Water liquld



Clean Water Axial-flow pump Matters Needing Attention

During the trial operation of Axial-flow pump, the connecting parts shall be checked to ensure that there is no looseness at the connecting parts.

Electrical appliances and instruments of Axial-flow pump shall work normally; There should be no leakage in the pipelines of the oil, gas, and water systems; Check that the pressure and hydraulic pressure are normal.

Regularly check for floating objects near the water inlet to prevent blockage.

The temperature of rolling bearing of Axial-flow pump shall not exceed 75 ℃. The temperature of the oil in the gearbox should be normal.

Pay attention to the sound and vibration of the water pump at all times, and immediately stop the machine for inspection if any abnormalities are found.



Cast Iron Vertical Turbine Water Pump Large Flow Rate For Water Liquld 0Cast Iron Vertical Turbine Water Pump Large Flow Rate For Water Liquld 1

Cast Iron Vertical Turbine Water Pump Large Flow Rate For Water Liquld 2





Cast Iron Vertical Turbine Water Pump Large Flow Rate For Water Liquld 3
