China Pulp Pumps Replace Andritz Pumps and Spares
Andritz S slurry pump introduction:
The parameters of ANDRITZ S series centrifugal pumps include flow rates up to 4000 m3/h, head up to 140 m, pump case pressure up to 16 kg, temperature up to 140 degrees Celsius, and concentration up to 6%. These parameters reflect the high standards of ANDRITZ S series centrifugal pumps, thanks to its rich experience in centrifugal pump performance and design innovation and in-depth knowledge of process know-how.
Andritz S slurry pump parameter table
Model | S |
Flow rate | 4000m3/h |
Head | 140m |
Pump casing pressure | 1.6Mpa |
Temperature | 140°C |
Concentration | 6% |
Impeller | Open impeller design |
Seal options | Single mechanical seal, Cartridge double mechanical seal |
Design features:
This series of pumps also features a modular system, and its standard parts can be used with other pump types, further improving its applicability and flexibility.
The design of the ANDRITZ S series centrifugal pumps also pays special attention to wear resistance and durability. The pump body and pump cover are protected by two wear-resistant liners, and the sturdy shaft ensures minimum shaft deviation and low vibration, thus ensuring the long life and low maintenance requirements of the pump.
The entire series uses only a few different sizes of bearing frames, providing a reliable open impeller design, which is characterized by low axial force and is suitable for conveying a variety of different media.
In terms of the sealing system, the ANDRITZ S series centrifugal pumps provide a variety of sealing options, including single mechanical seals that do not require external sealing water and containerized double mechanical seals that require external sealing water, etc., to meet the needs of different working conditions.
Andritz S pulp pumps and pump spare parts field applications:
ANDRITZ S series centrifugal pumps are widely used to transport clean and solid particles, demonstrating their superior performance in efficiency, service life, easy maintenance and economic benefits, and can meet the requirements of high-end customers.
