Rotor Diameter 300-1480mm Water Ring Vacuum Pump for High Temperature Environments

Rotor Diameter 300-1480mm Water Ring Vacuum Pump for High Temperature Environments

1480mm Water Ring Vacuum Pump

High Temperature Water Ring Vacuum Pump

Temperature Resistant Water Ring Vacuum Pump

Place of Origin:

China

Brand Name:

Huatao

Certification:

ISO 9001

Model Number:

HT-Rotary vane vacuum pump

Contact Us

Request A Quote
Product Details
Name:
Water Ring Vacuum Pump High Temperature Resistant
Impeller:
Open
Feature:
Friction Resistance /Corrosion Resistance
Hardness:
32-460m3/H
Noise:
66 DB
Power:
2.2kw
Rotor Diameter:
300~1480mm
Voltage:
380V、660V、6kV
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
USD 400-1300 per set
Packaging Details
Wooden Box
Delivery Time
35~50 days
Payment Terms
L/C, T/T, Western Union,
Supply Ability
200 sets per month
Product Description

Water Ring Vacuum Pump High Temperature Resistant



The pump can transfer the mechanical energy of the prime mover or other external energy to the liquid to increase the energy of the liquid. Pumps are mainly used to transport water, oil, acid-base liquids, emulsions, suspended emulsions, liquid metals and other liquids, as well as liquids, gas mixtures and liquids containing suspended solids.

We have many different types of pumps, such as centrifugal pumps, dual-fluid centrifugal pumps, low pulse pumps, medium concentration slurry pumps, and water ring vacuum pumps. The production process is 3D printing → mold making → casting, machining → dynamic balancing test → assembly → performance test → packaging.



Water Ring Vacuum Pump High Temperature Resistant Specification



Model Pumping Speed(m3/min) Ultimate Pressure(MPa) Motor Power(KW) Motor Speed(r/min) Water required(L/min) Inlet size(mm) Outlet size(mm) Weight(kg)
2SK-0.4 0.4 -0.097 2.2 2840 5~8 G1'' G1'' 120
2SK-0.8 0.8 -0.097 3 2880 10~15 G1'' G1'' 150
2SK-1.5 1.5 -0.097 4 1440 20~25 40 40 230
2SK-3 3 -0.097 7.5 1440 30~40 40 40 320
2SK-6 6 -0.097 15 1460 45~50 50 50 500
2SK-9 9 -0.097 18.5 970 50~60 100 100 700
2SK-12 12 -0.097 22 970 60~70 100 100 800
2SK-15 15 -0.097 30 970 80~90 100 100 1000
2SK-20 20 -0.097 37 740 100~120 125 125 1650
2SK-25 25 -0.097 45 740 120~140 125 125 1800
2SK-30 30 -0.097 55 740 130~160 125 125 1950



Water Ring Vacuum Pump advantage


1. Direct connection, simple structure, small size

2. Impeller material: alloy copper integral casting

3. Pump shell coating treatment to prevent wear

4. Use customized anti-corrosion mechanical seals

5. All motors have passed CE certification and are produced by ourselves to ensure quality.
